Motion Detection 2.0
Human/Vehicle Analysis
Deep learning-based motion detection 2.0 is enabled by default for all analog channels,
it can classify human and vehicle, and extremely reduce false alarms caused by objects
like leaves and lights;
Quick search by object or event type is supported;
Recording
Video Compression H.265 Pro/H.265
Encoding Resolution 1080p Lite/720p/720p Lite/WD1/4CIF/CIF/QVGA
Frame Rate
Main stream:
1080p Lite/720p/720p Lite/WD1/4CIF@25 fps (P)/30 fps (N)
Note:
1080p Lite/720p is 15 fps by default
Sub-stream:
4CIF@15fps; CIF/QVGA@25 fps (P)/30 fps (N)
Video Bitrate
According to the actual scene, scene-adaptive bitrate control technology would
automatically allocates appropriate bitrate to ensure the stability of recording period.
Stream Type
Video, Video & Audio
Note: In order to protect privacy, the device will only record video (without audio) by
default. If you want to record audio, you shall manually enable audio recording. For
operation details, refer to the user manual.
Audio Compression G.711u
Audio Bitrate 64 Kbps
Video and Audio
IP Video Input
1-ch
Up to 1080p resolution
Support H.265+/H.265 IP cameras
Analog Video Input
4-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI Input 1080p25, 1080p30, 720p25, 720p30
AHD Input 1080p25, 1080p30, 720p25, 720p30
CVBS Input Support
HDCVI Input 1080p25, 1080p30, 720p25, 720p30
HDMI Output 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
VGA Output 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output Mode HDMI/VGA simultaneous output
Audio Input 4-ch via coaxial cable
Audio Output 1-ch via HDMI
Synchronous playback 4-ch
Network
Total Bandwidth
64 Mbps
Incoming bandwidth: 4 Mbps
Network Protocol TCP/IP, DHCP, HiLookVision, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS
Remote Connection 32
Network Interface 1, RJ45 10/100 Mbps self-adaptive Ethernet interface
Auxiliary Interface
Capacity
Built-in 1024 GB eSSD (960 GB available)
Note:
The device can store about 8 weeks videos for 4-ch analog cameras (default parameters),
this estimation is for reference only.
USB Interface Rear panel: 2 × USB 2.0
Alarm In/Out N/A
General
Power Supply 12 VDC, 1 A
Consumption ≤ 5.4 W (with eSSD)
Working Temperature -10 °C to 45 °C (14 °F to 113 °F)
Working Humidity 10% to 90%
Dimension (W × D × H) 151 × 121 × 46 mm (5.94 × 4.76 × 1.81 inch)
Weight ≤ 0.5 kg (with eSSD, 1.1 lb.)
